Refuse Compactor

Description:

Waste Compaction for Efficient Waste Transport

Refuse Compacto G-PX is a lineup of garbage compactor trucks for the safe and efficient collection of waste. The advanced level of features for loading, compacting and transportation are sure to meet your needs. Making the collection process easy and efficient has made G-PX models popular the world over. Our lineup of garbage compactor trucks with a range of loading capacities.

ModelGT042GT053GT063GT084GT105GT127GT150GT200
Body capacity (m3) 4.3 5.2 6.0 8.6 10.2 12.0 15.3 20.0
Hopper capacity (m3) 0.6 0.7 1.1 1.0 (1.1) 2.2
Plate thickness (mm)BodyRoof*1
 2.1 2.3
Side*2
 2.7 2.3 2.7
Floor *1
 2.7 3.2
Discharge plate *1 2.1 2.1
HopperBottom*3 6.0 8.0
Side(upper)*3
 4.5 4.5
Side(lower)*3     4.5 4.5
Press plate*3 4.5 4.5
Loading time [one cycle] (sec) 10-11 13-20 26-28
Gate width (mm)    1,430 1,680 1,700 1,600 2,000
Sewage Scatter Prevention Rubber Equipped
Hopper Alarm (rising/descending) Equipped
Discharge time (sec) 10-20 10-25 15-25 45 55
Sewage Tank (L) 80 95 120 80 140
Anti-rust paint Electro-Deposition paint Anti-rust paint
Emergency Stop Button Hopper Both Sides

The above mentioned figures are approximate.

  • Optional equipments are included in these photographs
  • Specifications and dimensions are subject to change without notice.
  • Material : Anti-corrosion Steel
  • Material : Anti-corrosion Steel or High-tensile Steel
  • Material : High-tensile Steel
